iRis XT Articulating Videoscope

Call for Price
*Price may change due to echange rate.
SKU
423265496

The iRis XT videoscope enables remote visual inspections in ATEX zones. This makes it possible for the first time to carry out inspections with a video endoscope in an explosion-hazardous environment.
The iRis XT is certified to II 3 G Ex ic nA IIC T4 Gc.

For the inspection of cavities, the ATEX video endoscope has a tip that can be controlled in all directions with powerful FOLED-Hybrid lighting. The images are displayed using the 5-inch screen and can be recorded as a photo and/or video on an SD card. The compact carrying device has an input hose (probe) with an external diameter of 4, 6 or 8 millimeters and is available in lengths from 1.5 to 7.5 metres.

iRis XT Articulating Videoscope

The iRis DVR XT Inspection System is a 'ready to go' Video kit which includes the iRis XT Inspection System (specified by articulation, diameter & working length) with one battery, charger and neck-holder in a iRis case.

Part No System Diameter Length DOV
4mm x 4-way
279-44015 iRis 44-15 DVR XT 4mm  1.5m
279-44020 iRis 44-20 DVR XT 4mm 2m
279-44030 iRis 44-30 DVR XT 4mm 3m
279-44040 iRis 44-40 DVR XT 4mm 4m
6mm x 4-Way
279-46015 iRis 46-15 DVR XT 6mm 1.5m
279-46020 iRis 46-20 DVR XT 6mm  2m
279-46030 iRis 46-30 DVR XT 6mm 3m
279-46040 iRis 46-40 DVR XT 6mm 4m
279-46050 iRis 46-50 DVR XT 6mm 5m
279-46060 iRis 46-60 DVR XT 6mm 6m
279-46075 iRis 46-75 DVR XT 6mm 7.5m
8mm x 4-Way
279-48015 iRis 48-15 DVR XT 8mm 1.5m 0°
279-48020 iRis 48-20 DVR XT 8mm 2m 0°
279-48030 iRis 48-30 DVR XT 8mm 3m 0°
279-48040 iRis 48-40 DVR XT 8mm 4m 0°
 279-48050 iRis 48-50 DVR XT 8mm 5m
279-48060 iRis 48-60 DVR XT 8mm 6m
279-48075 iRis 48-75 DVR XT 8mm 7.5m

SPECIFICATIO

Operating unit
 Display size: 5.0“ (12.7cm) TFT colour
 Display resolution: VGA (640x480 pixel)
 Operating system: Real-time operating system, with on-screen menu
 User interface: Direct action keys / function keys / arrow keys
 Languages: English, German, Polish, French, Spanish, Italian, Turkish
 Power supply, primary: Rechargeable Li-ion battery
 (charger and battery are provided in delivery set)


Documentation
 Video format: MPEG4 (.avi) (with time and date stamp)
 Image format: BMP (.bmp) (with time and date stamp)
 Storage: SDHC memory card up to 32GB
 (FAT32) (8GB is provided in delivery set)


Camera control
 Image sensor: Advanced chip on the tip image sensor
 White balance: Factory default or user defined


Image control
 Zoom: 16 step digital zoom
 Invert: Horizontal and vertical image inversion
 Brightness: Adjustable
 Contrast: Adjustable
 Colour: Adjustable
 Text annotation: Built-in text overlay generator


Illumination
Type: High-power LED with high transmission fi ber optics
Illumination control: 3 steps
Colour temperature: approx. 6500k
Average lamp lifetime: approx. 5000h Probe
 Diameter: 4.0mm, 6.0mm 8.0mm
 Working length: as table above
 Articulation (bending neck): 2way / 4way 360° control 4-way 360° control
 Integrated objective lens: 90° FOV 90°FOV
 Braid: Multi-layer tungsten braid on PU jacket


Operating Environment
 Tip operating temperature: -13°F to 176°F (-25°C to +80°C)
 System operating temperature: -13°F to 115°F (-25°C to +46°C)
 Storage temperature: -13°F to 140°F (-25°C to +60°C)
 Relative humidity: 95% max. - non condensing
 Waterproof: Probe and distal end up to 14.7 psi
 (1 bar- 10.2m H2O)
 Resistance: Probe and distal end to oils and saline (5%)
 Carrying Case: 508mm x 373mm x 147mm / 4,5kg


Manufacturer‘s Data
Country of Origin Germany
