POLARIS REMOTE HMI 19.1" - Zone 1/21
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
The POLARIS Remote 19.1" unit by BARTEC is a display which a PC can be operated in safe areas of hazardous areas.Distances of up to 10000 m are possible. POLARIS Remote 19.1" offers the user the possibility of using any currently available PC-based process control system, without any restrictions in the Ex area.
POLARIS REMOTE HMI 19.1" - Zone 1/21
DESCRIPTION
The POLARIS Remote 19.1" unit by BARTEC is a display which a PC can be operated in safe areas of hazardous areas.Distances of up to 10000 m are possible. POLARIS Remote 19.1" offers the user the possibility of using any currently available PC-based process control system, without any restrictions in the Ex area. The front panel installation assures ease of mounting. On request, the devices are also available as turn-key system solutions in a Stainless-steel enclosure as wall, floor or ceiling mounting versions. The screen of the Remote 19.1" is a TFT display with an SXGA resolution and is characterised by its excellent brilliance and a very large reading angle.Intrinsically safe input devices can also be connected. The optional touchcreen (intrinsically safe) offers the ultimate in operating comfort. Connection in the safe area is realised via a local unit (included in scope of delivery).
FEATURES
- Easy front panel fitting
- Graphic-capable TFT colour display
- Easy wiring
- Connection of standard PCs in non-hazardous areas
- Optional touch screen
- Transmission through fibre optical waveguide or copper
- OSD menu, with setting keys on the front
- Reduction in costs by cascading several POLARIS remote devices to one PC
TECHNICAL DATA
| Protection class | IP 65 (front) IP 54 (back) |
| Structure | Front-panel fitting |
| Dimensions | 498 mm x 400 mm x approx. 135 mm |
| Wall cut-out | 484 mm x 386,5 mm + 0,5 mm |
| Material | Front: polyester foil on anodised aluminium plate (conditionally UV-resistant) Back: bichromated sheet steel |
| Cable length | POLARIS: terminals in the Ex e chamber Local unit: RJ45 connector Up to 300 m via STP copper cable VGA/PS2 (RS232 Touch) Up to 100 m via STP copper cable DVI/USB Optical fibre version POLARIS: ST connector Local unit: LC connector Up to 500 m via multi-mode optical fibre (50 μm/125) DVI/USB Up to 20 km via single-mode optical fibre (9/125 μm) DVI/USB |
| Storage temperature | -20 °C to +50 °C |
| Vibration | 0.7 g/1 mm; 5 Hz - 500 Hz pulse in all 3 axes |
| Shock resistance | 15 g/11 ms pulse in all 3 axes |
| Weight | approx. 33 kg |
| Display | 19.1" graphics-capable TFT colour display 16.7 million colours SXGA resolution 1280 x 1024 pixels Brightness 300 cd/m2 Visible area approx. 380 x 305 mm Contrast 1300:1 Antireflection-coated glass pane Optional touchscreen |
| Voltage | AC 90 to 253 V, 50 to 60 Hz DC 24 V ± 10 % on request |
| Power | Pmax. < 60 W |
ACCESSORIES
| Accessory | Price | Datasheet |
| Keyboard | Call For Price |  Datasheet.pdf |
| Enclosure for Mouse and Keyboard | Call For Price | Datasheet.pdf |
| Mouse | Call For Price | Datasheet.pdf |
| Trackball, Joystick | Call For Price | Datasheet.pdf |
| Touchpad | Call For Price | Datasheet.pdf |
| Connection Cable for Keyboard and Mouse | Call For Price | Datasheet.pdf |
| Reinforcement Frame | Call For Price | Datasheet.pdf |
| Mounting Clamps Set | Call For Price | Datasheet.pdf |
| LAN STP Cable | Call For Price | Datasheet.pdf |
| Power Pack for Local Unit | Call For Price | Datasheet.pdf |
| 19" Rack Mounting for Local Unit | Call For Price | Datasheet.pdf |
| USB to PS/2 Converter | Call For Price | Datasheet.pdf |
| Local Unit/STP Cable Black Box Brand | Call For Price | Datasheet.pdf |
| Local Unit/STP Cable IHSE Brand | Call For Price | Datasheet.pdf |
| KVM Cable | Call For Price | Datasheet.pdf |
| Standard Stainless Steel Enclosure with Adapter Connection without Stand | Call For Price | Datasheet.pdf |
| Exclusive II Stainless Steel Enclosure with Adapter Connection | Call For Price | Datasheet.pdf |
| Stainless Steel Enclosure - Swivel/Tilt without Desktop Mount | Call For Price | Datasheet.pdf |
| Desk Mounting for Enclosure 15"/19.1" Series | Call For Price | Datasheet.pdf |
| Support Arm for Wall Mounting | Call For Price | Datasheet.pdf |
| Stand for Floor Mounting for Exclusive II Stainless Steel Enclosure | Call For Price | Datasheet.pdf |
| Standard Stainless Steel Enclosure with Additional Fitted Components | Call For Price | Datasheet.pdf |
APPROVALS
ATEX:
II 2G Ex db eb qb [ib op pr] IIC T4 II 2D Ex tb IIIC T120 °C
IECEx:
Ex db eb qb [ib op pr] IIC T4
Ex tb IIIC T120 °C
DOWNLOADS
PRICES
ATEX and IECEx Zone 1 and 21
| Distance up to 100 m via STP cable DVI/USB | 17-71V2-5017 | € 8.631,00 |
| Distance up to 300 m via STP cable VGA/PS2 | 17-71V2-5000 | € 8.631,00 |
ATEX Zone 2 and 22
| Distance up to 100 m via STP cable DVI/USB | B7-72V2-5017 | € 6.904,00 |
| Distance up to 300 m via STP cable VGA/PS2 | B7-72V2-5000 | € 6.904,00 |
