SWAR0033-440X0 Ex proof cellular MiFi router/access point - Atex Zone 1

Call for Price
*Price may change due to echange rate.
SKU
87658963433

The Solexy SWA/SWS R0* is a compact, costeffective and secure industrial 4G/LTE Wi-Fi router for installation in harsh environments and hazardous locations. It is used to create a WiFi Hotspot based on a cellular connectivity. External N or SMA/RP-SMA antenna connectors make it possible to attach desired antennas and easily find the best signal location.

SWAR0033-440X0 Explosion proof cellular router and access point - Atex Zone 1

*There are many options for this model. Price is estimated.

The Solexy SWA/SWS R0* is a compact, costeffective and secure industrial 4G/LTE Wi-Fi router for installation in harsh environments and hazardous locations. It is used to create a WiFi Hotspot based on a cellular connectivity. External N or SMA/RP-SMA antenna connectors make it possible to attach desired antennas and easily find the best signal location.

SWA/SWSR0* Industrial LTE router have industry leading security features and widely used for 4G backup, Remote Connection, Out-of-Band Management, Advanced VPN and tunneling services in IoT networking solutions. With Solexy’s SWA and SWS enclosures and their rugged construction combined with Atex, IECEx and North America certificates, Solexy offers a wireless device solution for installation in classified Ex areas (gas, dust and mining) and harsh environments.



FEATURES:

OPERATING FUNCTIONS
WiFi access point (Wifi to LAN or WiFi to 2G/3G/4G)
WiFi client (LAN to WiFi)

DATA RATE
4G (LTE) Cat 4 up to 150 Mbps
3G up to 42 Mbps and 2G up to 236.8 kbps

WIRELESS
IEEE 802.11 b/g/n Access Point (AP) and Station (STA)

SMS TOOLS
SMS status, SMS configuration, send/read SMS
via HTTP POST/GET

HEAVY DUTY CONSTRUCTION
Explosion proof enclosure made in alluminum (SWA series)
or stainless steel (SWS series) weather proof IP66/68




Specifications

 GENERAL

Power supply

9 - 30 VDC, Passive PoE

Power consumption

5W

Ambient temp. range

USA & CANADA

ATEX & IECEx

SWA series -40°C (-40°F) +75°C (+158°F)

SWS series -40°C (-40°F) +75°C (+158°F)

SWA series -40°C (-40°F) +68°C (+154°F)

SWS series -40°C (-40°F) +61°C (+141°F)

HARDWARE

CPU

Atheros Hornet, MIPS 24Kc, 400 MHz

Memory

RAM 64MB, DDR2, Flash 16MB SPI

I/O

1 x Digital Input, 1 x Digital Output

Ethernet

2 x RJ45 ports, 10/100 Mbps

Network connection

4G

Cat 4 up to 150 Mbps

3G

Up to 42 Mbps

2G

Up to 236.8 kbps

Supported bands*

4G (LTE-FDD)

B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B26, B28

* in function of device installed

4G (LTE-FDD)

B38, B39, B40, B41

3G

B1, B2, B4, B5, B6, B8, B19

2G

B2, B3, B5, B8

WiFi

802.11 b/g/n - Up to 50 simultaneuos connection

SOFTWARE

Management

WEB UI

HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log

FOTA

Firmware update from sever, automatic notification



SSH

SSH (v1, v2)



SMS

SMS status, SMS configuration, send/read SMS via HTTP POST/GET



SNMP

SNMP (v1, v2, v3), SNMP trap



JSON-RPC

Management API over HTTP/HTTPS



MODBUS

MODBUS TCP status/control



RMS

Remote Management System (RMS)



VPN

OpenVPN

Multiple clients and server can be running simultaneously, 12 encryption methods

IPsec

IKEv1, IKEv2, supports up to 4x VPN IPsec tunnels (instances), with encryption



GRE

GRE tunnel



PPTP, L2TP

Client/Server services can run simultaneously



Stunnel

Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the programs’ code.



SSTP

SSTP client instance support




APPROVALS:

ATEX / IECEX CERTIFICATION
Zone 1, 2, 21 & 22
II 2 G Ex db IIC T5-T4 Gb
II 2 D Ex tb IIIC T110°C/T140°C Db
I M2 Ex db I Mb (SWS only)

USA & CANADA CERTIFICATION
Class I, Division 1, Groups B, C and D
Class II, Division 1, Groups E, F and G
Class I, Zone 1, Groups IIB+H2 [For U.S. only]
Zone 21, Groups IIIC [For U.S. only]

Approvals MSHA
