Apple iPad Mini 5 | Atex XCZ1 Zone 1 Case | 7,9" | (Case Only)
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
You'll be able to use the most popular tablet in the world in a ATEX / IECEx Zone1 area.
You'll be able to use the Apple iPad mini 5 in a Zone 1 area with explosive gas atmospheres. The Xciel XCZ1 case is IECEx certified (IECEx EXV 19.0026X, Ex db IIC T5 Gb). ATEX documentation on request.
*This is the case only. It is also possible to purchase the tablet from us.
Under the conditions of the IECEx certificate, the iPad mini shall not be removed from the aluminium case. Xciel states that removal of the XCZ1 enclosure from the iPad can only be performed by an Xciel employee or authorised partner. Please contact us about fitting the iPad before you order.
Also available: (Ask for more info)
Certification
The XCZ1 case for the iPad mini 5 is a flameproof aluminium enclosure, type of protection Ex db. For buyers looking for an explosion proof or intrinsically safe iPad mini: the protection concept is a flameproof enclosure, as stated on the IECEx certificate. It is not intrinsic safety.
| IECEx certificate | IECEx EXV 19.0026X, issue 2 (22 June 2023), status Current, issued by ExVeritas Limited, United Kingdom. Earlier issues: issue 0 (4 July 2019) and issue 1 (22 April 2021). |
| IECEx marking | Ex db IIC T5 Gb (-20 °C < Tamb < +45 °C) |
| Type of protection | Flameproof enclosure "d", level of protection db |
| Standards (IECEx) | IEC 60079-0:2017 (Ed. 7.0), IEC 60079-1:2014 (Ed. 7.0) |
| Certified equipment | Flameproof iPad Mini, model numbers XCZ1 Mini followed by 4 or 5, optionally followed by -WOC (additional metal tabs covering the front and rear cameras of the iPad) or -NIC (metal tabs, and the internal camera modules of the iPad are removed). Aluminium enclosure with a sapphire glass window, general dimensions 171 x 240 x 17 mm according to the certificate. |
| Zones | Zone 1 and Zone 2, explosive gas atmospheres only (equipment protection level Gb) |
| ATEX | ATEX documentation on request |
| Manufacturer | Xciel Inc., Richmond, Texas, United States |
Reading the marking
Ex db: flameproof enclosure, level of protection "db". This is not intrinsic safety (Ex ia, ib or ic).
IIC: gas group IIC, which also covers IIA and IIB. IIC includes hydrogen and acetylene.
T5: temperature class T5, maximum surface temperature 100 °C.
Gb: equipment protection level Gb, for Zone 1 and Zone 2.
Not for Zone 0 and not for dust: equipment protection level Gb is not for Zone 0, and the marking has no dust part, so the case is not certified for Zone 21 or Zone 22.
Specific conditions of use (X)
The certificate number carries the suffix X. The IECEx certificate states the following specific conditions of use:
- The iPad mini shall not be removed from the aluminium case.
- The iPad mini shall not be charged when hazardous atmospheres are present.
- Resellers and end users are not allowed to repair the flameproof joints. Xciel Inc. is not allowed to repair the flameproof joints either.
- The cover bolts should not be removed. They may only be replaced with identical ones: A2 stainless steel M5 x 0.8 x 8 mm Torx head (or pan head if Torx head is not available), with a tensile strength of at least 500 MPa, installed with a torque of 5.9 Nm.
- After recharging the iPad mini, inspect the threads of the power plug and the female threads before re-installation. Install the power plug with all threads fully engaged and tighten the set screw with the tool provided. Then check that the set screw sits in the groove of the power plug head (M4 x 0.70 mm A2-70 6H stainless steel cup point hexagon socket set screw).
- Rubber bumpers must be installed on the equipment at all times to protect the corners of the aluminium case, and must be visually inspected for good condition before each use.
Downloads
XCZ1 iPad mini 5 datasheet (Xciel, PDF)
IECEx certificate IECEx EXV 19.0026X, issue 2 (IECEx website)
Datasheets
-
![XCZ1 Mini 5 Kit (Zone 1 iPad Mini 5)]()
