ATEX iPad (A16) Zone 2/22 - Armadex Ex UniCase Set
*Prices are Excl. VAT, duty and shipping costs and may change due to exchange rate.
Complete set of the ATEX and IECEx certified Armadex Ex UniCase enclosure, the device-specific inlay set and an Apple iPad (A16), 11 inch, for Zone 2 (gas) and Zone 22 (dust). Available with 128, 256 or 512 GB storage, Wi-Fi or Wi-Fi + 5G, marked II 3G Ex nR IIC T6 Gc and II 3D Ex tc IIIC T85°C Dc.
ATEX iPad (A16) for Zone 2/22: Armadex Ex UniCase set
Certifications: ATEX OBAC 26 ATEX 0194X • IECEx OBAC 26.0005X | Zones: Zone 2 (gas) • Zone 22 (dust) | Protection: Ex nR • Ex tc • IP64 | Manufacturer: Armadex Explosion Protection B.V.
This complete set combines the Armadex Ex UniCase enclosure, the device-specific inlay set and an Apple iPad (A16), 11 inch. It is intended for buyers looking for an ATEX or explosion proof tablet for Zone 2 (gas) and Zone 22 (dust). The enclosure is certified under ATEX (OBAC 26 ATEX 0194X) and IECEx (IECEx OBAC 26.0005X) and carries the marking II 3G Ex nR IIC T6 Gc and II 3D Ex tc IIIC T85°C Dc.
The UniCase provides mechanical protection while the touchscreen, cameras, microphones and speakers of the iPad remain accessible. The USB-C port is accessible as well, for use outside the hazardous area only. If the iPad needs to be replaced or renewed, this can be done without modifying the certified enclosure.
Configurations and prices
| Storage | Network | SKU | Price excl. VAT |
|---|---|---|---|
| 128 GB | Wi-Fi | UC-SET-IPAD-A16-128-WIFI | EUR 2,121 |
| 128 GB | Wi-Fi + 5G | UC-SET-IPAD-A16-128-5G | EUR 2,261 |
| 256 GB | Wi-Fi | UC-SET-IPAD-A16-256-WIFI | EUR 2,228 |
| 256 GB | Wi-Fi + 5G | UC-SET-IPAD-A16-256-5G | EUR 2,369 |
| 512 GB | Wi-Fi | UC-SET-IPAD-A16-512-WIFI | EUR 2,435 |
| 512 GB | Wi-Fi + 5G | UC-SET-IPAD-A16-512-5G | EUR 2,575 |
| Enclosure only, for your own Apple iPad (A16), 11 inch | UC-CASE | EUR 1,700 | |
Mention the SKU of the configuration you need in your order or quote request.
Why this set
ATEX and IECEx for Zone 2 and 22
The enclosure holds ATEX type examination certificate OBAC 26 ATEX 0194X and IECEx certificate IECEx OBAC 26.0005X, both issued by OBAC Sp. z o.o. in Gliwice, Poland, for Zone 2 (gas) and Zone 22 (dust).
Ex nR and Ex tc protection
Gas protection is based on restricted breathing (Ex nR), dust protection on protection by enclosure (Ex tc). The enclosure has degree of protection IP64.
The iPad stays usable
The touchscreen is operated through the display window. Three stainless steel push buttons operate the physical buttons of the iPad via a patented inlay system.
ESD-safe POM-C enclosure
Milled frame of ESD-safe POM-C with an impact-resistant display window and a transparent back plate, sealed by a 3 mm silicone rubber O-ring.
Modular design
Device-specific, modular ABS corner inlays hold the iPad in position. The iPad can be replaced or renewed without modifying the certified enclosure.
Six configurations
Choose 128 GB, 256 GB or 512 GB of storage, each with Wi-Fi or with Wi-Fi + 5G. The enclosure is also available on its own for your own iPad (A16).
Technical specifications
Tablet: Apple iPad (A16), 11 inch
| Platform | Apple iPad (A16), 11 inch |
| Chip | Apple A16, 5-core CPU, 4-core GPU, 16-core Neural Engine |
| Storage | 128 GB, 256 GB or 512 GB |
| Display | 11 inch Liquid Retina (LED-backlit IPS), 2360 x 1640 pixels, 264 ppi |
| Brightness | 500 nits |
| Rear camera | 12 MP wide, f/1.8 |
| Front camera | 12 MP Center Stage (landscape), f/2.4 |
| Wireless | Wi-Fi 6 (802.11ax) with 2x2 MIMO, Bluetooth 5.3 |
| Mobile network | 5G sub-6 GHz (Wi-Fi + 5G configurations) |
| Tablet dimensions | 248.6 x 179.5 x 7.0 mm (tablet without enclosure) |
| Tablet weight | 477 g (Wi-Fi), 481 g (Wi-Fi + 5G), tablet without enclosure |
| Battery | Internal 28.93 Wh lithium-polymer battery, up to 10 hours of use according to Apple |
| Operating system | iPadOS |
Enclosure and certification: Armadex Ex UniCase
| ATEX marking | II 3G Ex nR IIC T6 Gc II 3D Ex tc IIIC T85°C Dc |
| IECEx marking | Ex nR IIC T6 Gc Ex tc IIIC T85°C Dc |
| ATEX certificate | OBAC 26 ATEX 0194X, Issue 0 (12 May 2026) |
| IECEx certificate | IECEx OBAC 26.0005X, Issue 0 (28 May 2026) |
| Zones | Zone 2 (gas) and Zone 22 (dust) |
| Protection concepts | Ex nR, restricted breathing (gas) Ex tc, protection by enclosure (dust) |
| Directive | 2014/34/EU (ATEX 114) |
| Standards (ATEX) | EN IEC 60079-0:2018, EN IEC 60079-15:2019, EN IEC 60079-31:2024 |
| Standards (IECEx) | IEC 60079-0:2017, IEC 60079-15:2017, IEC 60079-31:2022 |
| Certification body | OBAC Sp. z o.o., Gliwice, Poland |
| Degree of protection | IP64 |
| Ambient temperature (operating) | -20°C to +50°C |
| Ambient temperature (storage) | -20°C to +60°C |
| Power supply (rated data) | Internal Li-ion battery, 3.7 to 7.6 V DC |
| User interface | Touchscreen and 3 mechanical push buttons |
| External port | USB-C, for use outside the hazardous area only |
| Wireless communication (certificate rated data) | Wi-Fi, Bluetooth |
| Materials | Milled frame of ESD-safe POM-C Transparent back plate, sealed by a 3 mm silicone rubber O-ring Impact-resistant transparent display window Device-specific, modular ABS corner inlays 3 stainless steel push buttons with patented inlay system |
| Manufacturer | Armadex Explosion Protection B.V., Ridderkerk, the Netherlands |
Specific conditions of use (X)
Both certificate numbers end in X. This means the following specific conditions of use apply:
- The Ex UniCase may only be opened or closed outside the hazardous area.
- The USB lid and the test port plug must always be fitted in the hazardous area.
- The device must be protected from impacts with high impact energy, from excessive UV light and from high electrostatic charge processes.
Applications
The Ex UniCase with Apple iPad (A16) is intended for professional use in Zone 2 (gas) and Zone 22 (dust) hazardous areas. Typical tasks include:
- Inspection
- Documentation
- Reporting
- Operation in the field
Documentation
- Datasheet Ex UniCase iPad (A16) (PDF, English)
- ATEX type examination certificate OBAC 26 ATEX 0194X (PDF)
- IECEx certificate IECEx OBAC 26.0005X (IECEx website)
See all supported tablets on the Ex UniCase overview.
