ATEX EX-MV01

Introducing the Venas EX-MV01, the world’s first Class I
Division 1, ATEX Zone 0 and IECEx ia safety certified
remote area light. Now you can take remote area lighting
to hazardous areas around the globe.
The 125° beam angle along with up to 1,600 lumens and
providing up to 10 hours of run time, this LED Lantern will
support full work shifts and deliver safe situational
awareness.
Weighing only 15.4 pounds and completely collapsible,
makes for easy carry and quick set ups.
The dual light modes, High/Low provide flexible options
and is equipped with a 30 minute visible low battery
warning indicator.
Safety approved for the most volatile work areas, this LED
Lantern is safe and one of the most compact, high output
lanterns on the market.

• 3 pre-set light output levels
• Up to 1,600 lumens (calculated)
• Up to 10 hrs of run time
• Full time battery level indication with low level
flashing indicator
• Deployable mast with 360 degree rotation
• Multiple deployment positions
• Valid over the entire temperature range from
-20°C to 40°C (-4 ºF to 104ºF)

CERTIFICATION

Marking Atex:
Ⅱ1 G Ex ia op is IIC T4 Ga
Ⅱ1 D Ex op is ta IIIC T135℃ Da IP66

Marking IECEX:
Ex ia op is IIC T4 Ga
Ex op is tb IIIC T135℃ Db IP66

Marking UL844:
(North American)

Class I, Division 1, Groups A, B, C, D
Class I, Division 2, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G
Class III
ATEX Zone 0 and IECEx ia

MATERIALS

Body:
Plastic

Head:
Aluminum Alloy

Lens:
Plastic

LIGHT SPECS

Lumens (Strong Light):
1600

Lumens (Work Light):
≥500

Lamp Heads:
1

Lamp Type:
LED

Beam Spread:
125°

IP Rating:
66

CCT Range:
3000-6500k

Rated Power:
5-19.5W

Rechargeable:
Yes

Charge Volts:
DC10.8V~14.4V

Battery Level Indicator:
Full-time battery level display and low battery warning (visible flashing)

Volts:
10.8V(Battery); AC100V/277V(Charger)

WEIGHT
weight: 15.4 lbs (7kg)

MODES

Light Modes:
High / Low / Flashing

DIMENSIONS
Dimension(L×W×H):
386[15.2]×210[8.3]×237[9.3]

Deployable Height 1:
Min.567[22.3]~Max.825[32.5]

Deployable Height 2:
Min.567[22.3]~Max.935[36.8]

COLORS
Color: Yellow
