Explosion Proof Station EX 7711 (EOL)
*Price may change due to echange rate.
Note this product is end of life (EOL)
Description Explosion Proof Station EX 7711
2-wire Explostion proof station with large graphic display and large, clear button field, specially designed for use when wearing protective gloves. The modular housing assures easy maintenance, so that for instance the microphone and keypad can be exchanged without opening the station. Volume electronically adjustable via keypad. Especially for use in explosion capable atmospheres Certified Zone I, Group IIB, T4
Features Explosion Proof Station EX 771
- Extremely rugged housing (IP 66)
- Integral amplifier and horn-loudspeaker
- 8 Row 14 Column Graphic display (EX 7711),
- LED-Display (EX 7411)
- Large keypad, especially suited for gloved hands
- Clearly visible luminous keypad
- Modular plug-in assemblies for ease of mantenance
- Hypercardioid noise-cancelling microphone
- Volume electronically adjustable via keypad
- Auxiliary items available, e.g. vandal resistant handsets, foot
and knee operated push-to-talk switches, ear-defender
headsets etc.
Measurements: W 190 mm, H 500 mm, D 120 mm
Weight: ca. 10,000 g
Specifications/Certificate Explosion Proof Station EX 7711
Certification: Sira 02 ATEX 1177X; Ignition-protection: II 2 G EEx d [ia]ib IIB T6 Tamb = -20° C to +50° C; IP-rating IP 66; built-in amplifier and horn loudspeaker; Power supply on site 24 V DC, 110, 220, 230 V AC, 50/60 Hz.
Downloads
PM0079.pdf
